Repair and inspection on gearbox EKATO EKF-3V-280-660-KR

We got this EKATO EKF-3V-280-660-KR gearbox in our shop in The Netherlands. After inspecting the gearbox, we did a complete overhaul and testing. After our quality control department was done, we send the gear unit back to our client. The work consisted of:

Disassembly, cleaning and inspection
Renew bearings, seals and various small materials
Assembly and adjustment
Test run with reporting
Preserve the gearbox externally in a 2-layer system

Additional work following inspection:

Clad input shaft with Stellite t.p.v. the seal
Check inside work / teeth manually
Install oil pump with new bearings and seals
Adjust outgoing link to Ina ring
Renewing clutch rubbers, oil level eye, and breather cap
Engineering and supervision
